Display Characteristics
| Screen size (inches) | 32 |
|---|---|
| Active display Area (mm) | 697.68 x 392.25 |
| Display mode | 16:9 |
| Panel type | TFT-LED |
| Native Resolution (pxl) | 1920 x 1080 |
| Supported resolutions | 480P,576P,720P,1080I, 1080P |
| Color display | 16.7M |
| Pixel Pitch (mm) | 0.294(H)x 0.294(V) |
| Brightness (cd/m2) | 250 |
| Contrast | 1000:1 |
| Refresh rate | 75 hz |
| Viewing angle (H/V) | 178°/178° |
| Response time (ms) | 5 |
| Backlight | LED |
| Auto On | No |
Input & output
| HDMI-CEC | No |
|---|---|
| HDMI 2.0 | 1 |
| VGA | Yes |
| BNC IN | 2 |
| Bnc output | 1 |
| USB | 1 |
| Power | 220V AC |
| Speaker | 2 x 3W |
Video
| Standard System | PAL/NTSC/SECAM |
|---|---|
| Osd control | Luminosité, Contrast, Position H/V, horloge, Phase, Couleur,Langue |
| 3d comb filter | Yes |
| Digital 3d noise reduction technology | Yes |
| Mounting style | Stand Mount, VESA 200 mount |
| Power supply (AC/DC) | 220V AC |
| Operating temperature range | -30 +85°C |
| Language | English/Italian/German/French/Spainish/Portuguese/Russian |
| Mouting (VESA) | 200 |
| MTBF (H) | 50000 |
| Working time without interruption | 24/7 |
Accessories
| Included in the box | PSU, Screw, cable , quick start guide, HDMI |
|---|---|
| Dimensions | (mm) : 740 x 480 x 92 |
| Weight (kg) | 5 |
| Chassis design | plastic |
| Warranty (year) | 4 |
ETIM features
| Type of display | LCD |
|---|---|
| Resolution | Full HD |
| Housing colour | Black |
| With display backlight | No |
| Colour display | Yes |
| Image format | 16:9 |
| With on-screen keyboard | No |
| With touch screen | No |
| Mouse-cursor control integrated | No |
| Supply voltage AC 50 Hz | 110 - 240 |
| Supply voltage AC 60 Hz | 110 - 240 |
| Voltage type (supply voltage) | AC |
| Number of HDMI connections | 1 |
| Number of BNC connections | 2 |
| VGA-connection (D-Sub 15-pole) | Yes |
| Number of ports USB-A | 1 |
| With HW-interface PS2 | No |
| Operating temperature | 00 - 50 |
| Horizontal frequency | 60 - 75 |
| Frame frequency | 60 - 75 |
| Freestanding | Yes |
| Suitable for rail mounting | No |
| Wall mounting/direct mounting | Yes |
| Front built-in possible | No |
| Rack-assembly possible | No |
| Mounting Interface Standard (MIS) according to VESA | 200x100 |
| Suitable for safety functions | Yes |
| Degree of protection (IP) | IP20 |
| Width | 738.1 mm |
| Height | 436.5 mm |
| Depth | 92.5 mm |
| Compatible with Apple HomeKit | No |
| Compatible with Google Assistant | No |
| Compatible with Amazon Alexa | No |
| IFTTT support available | No |
