GGM PRJC6A10G

10G C6A SCREENED JACK TOOL FREE

The tool-free GGM PRJC6A10G core combines CAT6A 10G performance with ease of installation. Requiring no insertion tools, it simplifies and reduces the work of connection. The kernel's color-marked wire guide system separates the pairs, ensuring better performance and faster installation.

Color code	T568A/B
Number of contacts	8
Connector type	RJ45
Applications	IEEE802.3 : 10GBase-T, 5GBase-T, 2.5GBase-T, 1000Base-T, 100Base-Tx, 10Base-T IEEE 802.3af/at/bt (PoE/PoE+/4PPoE)
Core shield	Shielded
Category	6A
Standards	ANSI/TIA-568.2-D ; EN 50173 ; ISO/IEC 11801
Connection mode	Toolless
Pins quality	50 micron gold contacts
Jauge_accepted_code_article	22/24
Dust cover	No
Packaging	By piece

ETIM features

Model	Bus (jack)
Type of connector	RJ45 8(8)
Screened	Yes
Connection type	Other
Special tool necessary	No
Suitable for round cable	Yes
Suitable for flat cable	No
Suitable for litz wire conductor	Yes
Suitable for solid conductors	Yes
Colour	Silver
Transparent	No
Compatible with Grade2TV according to XP-C 90-483	Yes
Compatible with Grade3TV according to XP-C 90-483	Yes
