GGM AXA2MFK2KW

AUTO CENTRAL 2R CLAV+MF IP66

The GGM AXA2 series is a standalone controller built to secure access in an automatic manner with authentication by card, pin or both at the same time. The AXA2MFK2KW standalone control panel has 2 independent relays and is able to manage up to 2,000 users. It is intended for outdoor use. The resin protection of the electronic card renders the product compliant with IP66 and its anti-vandal resistance allows its use in difficult environments Its compact design and silver-black colour creates a discrete product for tertiary installation, industrial sites, banks or sensitive sites. The card format supported is Mifare Classic 13.56 MHz This standalone control panel can be programmed in 7 different functional modes: Autonomous reading for 1 or 2 doors Anti-passback for 1 or 2 doors Wiegand 26 bit reader for connection to a central control Autonomous reading with inter-locking of the 2 relays Easy to install and program, this product is the perfect partner for small access control installations.

Controller type	Autonomous
Authentication method	Mifare keypad + rfid
Maximum number of users	2000
Card type	Mifare Classic (13.56 MHz)
Impact resistance	Vandal proof
Color	Silver / black

ETIM features

Model	Controller unit
Standalone	Yes
Networkable	Yes
PC-binding	No
Cloud-based system	No
Max. number of doors	2
Type of interface	None
Max. number of users	2000
Type of reading technique	Code
Reading strategy iClass/iClass SE (13.56 MHz)	No
Reading strategy magnet strip	No
Reading strategy MIFARE (13.56 MHz)	Yes
Reading strategy EM (125 kHz)	No
Reading strategy DESfire (13.56 MHz)	No
Reading strategy SEOS (13.56 MHz)	No
Mounting method	Surface mounted
Operating voltage DC	12 - 12
Operating temperature	-35 - 60
Degree of protection (IP)	IP66
Colour	Silver
Width	55 mm
Height	145 mm
Depth	22 mm
