GGM PTO4SCAPCS
ONT loaded with 4 SC/APC simplex green adapters with shutters
Compact, these terminal wall boxes are intended for FTTx applications. They allow 2 to 4 fibres to be connected on SC simplex connectors.
Read more
Compact, these terminal wall boxes are intended for FTTx applications.
They allow 2 to 4 fibres to be connected on SC simplex connectors.
| Materials | ABS plastic |
|---|---|
| Protection (IP) | IP53 |
| Capacity | 4 fibers |
| Cable entry | Top, side and bottom cable entries |
| Included | fixing accessories |
| Operating temperature range | -20°C to +85°C |
| Weight (kg) | 0.091 |
| Surface mounted | Yes |
| Flush-mounted installation | No |
| Duct installation | Yes |
| Floor box/Sub floor mounted | Yes |
| Connection method | Other |
| With adapters | Yes |
| Number of connections | 4 |
| Connector type | SC |
| Colour | White |
| RAL | 9010 |
| Central plate | No |
| With cover frame | Yes |
| Labeling zone | Yes |
| Separate strain relief | No |
| Fibre routing / Cable management | Yes |
| Outlet direction | Angled |
| Dust cover | Hinged lid |
| Device width | 80 mm |
| Device depth | 28 mm |
| Device height | 80 mm |
