GGM NVR0416

NVR 16 CHANNEL 4 EMPL HDD FREE

The GIGAMEDIA recorders give an excellent price/performance ratio for video surveillance installations. The NVR0416 is a dedicated recorder for important video surveillance. It allows up to 16 IP GIGAMEDIA cameras to be recorded. It has FOUR places able to take hard disks with a maximum capacity of 6Tb. It accepts cameras up to 4K resolution. It has 16 dry contact inputs for alarm recordings. The UpNp and P2P functionalities allow for an easy remote access configuration. The mobile application GGM VIEW is available on IOS and android platforms. This product will be ideal for safeguarding your projects (tertiary, industrial, logistics…

Mobile app	GGM VIEW
UPNP function
OS	Linux embarqué
CPU	ARM processor
Flash	NAND128MB
RAM	4*4Gb
Display live view	1x1;2x2;3x3;3x4;4x4;1+5;1+7;2+8;1+9;1+12;4+9;1+1+12
Number of camera supported	16
Graphics interface	HDMI x 2 VGA x 1
Resolution	1024768, 1280720, 12801024, 1440900, 19201080 , 25601440, 3840*2160
Camera grid	Change the view cell camera on live view screen
Dewarp fisheye	1O,VR，3D Cylinder，2PTZ，4PTZ，180 Panorama，360 Panorama，360 Panorama + 1/3/6/8PTZ，Fisheye + 3/8PTZ
Stream	Main stream/Sub stream
PTZ functions	Control direction, Home, iris, Preset,Cruise, Patrol
Display enhancement	OSD NVR, OSD camera, camera information, I/O remote control, event notification
Video Format	H.264/H.264+/H.265/H.265+/MJPEG
Décoding resolution	8MP,5MP, 3MP ,2MP(1080P),1.3MP(960P),1.0MP(720P)
Decoding capacity	4K:60fps 4MP:120fps 2MP:240fps
SPOT FUNCTION	No
Audio Format	G.711A;G.711U
Audio Input /output	3,5 mm audio Jack output 3,5 mm audio input
Recording time	Pré-recording: 10S Post recording: 30s,1,2,5min
Recording stream	Main stream/Sub stream
Continous recording	256Mbps
Recording type	Continuous / Manual / Schedule / Motion detection / Sensor Triggered/Intelligents
Number of HDD	4
HDD capacity (Tb)	10 tb each
RAID
HDD management	create, format ,overwrite, remove hdd HDD Smart
Manual backup	usb dongle,CD/DVR driver
Scheduled backup	FTP,Cloud,drop box
Playback display	4/9/12/16 channel simultaneously : multiple display 1 x 1
Playback control	Play, Stop, Pause, next frame, speed control, Schedule, sacle,
Video search	Alarm,event,picture,schedule, date/time, intelligent
Snapshot	.jpg/.jpeg
Export video clip	.AVI/.RF/.MP4
Network Interface	RJ-45 port (100/1000M）
Number of POE port
Number_of_WAN_port_article	1
Bitrate	256Mbps
Protocols	TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE, SMTP,NTP,UPnP,SNMP,HTTPS,FTP,
USB	1x3.0 USB for backup/upgrade , 2x 2.0 USB for mouse
Number of Digital input	16
Number of Digital output	1
Audio	1 output jack 3,5 mm
RS485	Yes
POS Integration	optional
UPS integration
Camera integration	Onvif V2.6 profile S
Event	Motion detection, alarm input, network failure, Occlusion detection, intelligents
Action	Recording, email, FTP, buzzer, Cloud notification,
User management	Administrator, Standard user
Log	System, recording, user, error
Date and Time	Time zone, Manual, Automatic synch, daylight saving time
Language	EN/CN/FR/PT/ES/SW …
Intelligent	Face Recognition, Human & Vehicle Detection, Perimeter Intrusion Detection, Line Crossing Detection, Stationary Object Detection, Crossing Counting, Heat Map, Crowd Density Detection, Queue Length Detection, License Plate Detection
Software	VMS pro
App	GGM VIEW
Web browser	IE10/11 Safari V12.1 above Firefox V.52 above Google chrome V.57 above Edge V.79 above
Rack mountable	yes using accessories
Power supply	12V/5A
Dimension	378325.866mm
Weight (kg)	3.5
Consumption (w)	6
Operating Temperature (°C)	-10°C - +50°C
Working humidity	0-90%
Max. number of control inputs	16
Number of hard disc bays	4
Memory capacity per hard disc	16 TB
