GGM NKJUC6TL

CAT6 SHORT UTP KEYSTONE JACK TOOL FREE

New small jack, tool free connection offering quick and efficient installation. It is certified CAT6 and 4 PPoE by an independent laboratory. The contacts are formed and positioned to reduce unwanted coupling between pairs and reduce the crosstalk. The completely automated production of printed circuits and a thorough inspection at the end of production guarantees the homogeneity of the fabrication. Disposing of “tool-free connection” technology the jack requires no insertion tool, which simplifies and reduces assembly time. Finally, its compact design (ultra-reduced depth of 28 mm) allows space to be optimised in the workstation trunking (facilitates the cable bending radius)…

Read more
Buy at Rexel
New small jack, tool free connection offering quick and efficient installation. It is certified CAT6 and 4 PPoE by an independent laboratory. The contacts are formed and positioned to reduce unwanted coupling between pairs and reduce the crosstalk. The completely automated production of printed circuits and a thorough inspection at the end of production guarantees the homogeneity of the fabrication. Disposing of “tool-free connection” technology the jack requires no insertion tool, which simplifies and reduces assembly time. Finally, its compact design (ultra-reduced depth of 28 mm) allows space to be optimised in the workstation trunking (facilitates the cable bending radius) and in the control panel with a 24 port solution in a 19″ 0.5U panel. Possibility to include a moveable white anti-dust shutter (except for 0.5U panel).
Color code T568A/B
Number of contacts 8
Connector type RJ45
Applications IEEE802.3 : 5GBase-T, 2.5GBase-T, 1000Base-T, 100Base-Tx, 10Base-T, IEEE 802.3af/at/bt (PoE/PoE+/4PPoE)
Core shield Unshileded
Category 6
Standards ANSI/TIA-568.2-D ; EN 50173 ; ISO/IEC 11801
Connection mode Toolless
Pins quality 50 micron gold contacts
Jauge_accepted_code_article 22/24
Dust cover Yes
Packaging By piece
Model Bus (jack)
Shielded No
Connection type Other
Specific tooling No
Adapted to round cables Yes
Adapted to flat cables No
Adapted to stranded cables Yes
Adapted to solid cables Yes
Colour Black
AWG range 22 - 24
