GGM D4MLCLC8M

LC/LC OM3 50/125 µm duplex 8 m patchcord, LSZH Ø1,8 mm jacket, aqua colour

Duplex fibre optic patch cords OM3 50/125 µm, grey sheath

Read more
Buy at Rexel
Duplex fibre optic patch cords OM3 50/125 µm, grey sheath
Cord type Duplex
Ferule High precision ceramic (ZrO2)
Sheath type LSZH
Reinforcement Aramid yarns
Cable diameter 2x 3 mm (multimode), 2x 2.80 mm (singlemode), 2x 1.80 mm (LC to LC)
Conformity EIA/TIA 568, ISO 11801, EN50173, IEC 61754, IEC 61300
Packaging Each
Other lengths and configurations On demand
Il/rl test report Supplied with each piece
Operating temperature From - 5°c to + 60°c
Mating cycles 1000 (0.2 db change)
Strength member : Aramid yarns
Fibre optic category Multi mode 50/125
Category OM3
Fibre count 2
Outer diameter sheath single fibre 1.8 mm
Shield type Duplex
Length 8 m
Connector A LC-Duplex
Connector B LC-Duplex
APC-version connection 1 No
APC-version connection 2 No
Jacket colour Turquoise
Boot Put-on
Halogen free according to EN IEC 60754-1 Yes

Product information

Data sheet
DOP/CPR
LC/LC OM3 50/125 µm duplex 1 m patchcord, LSZH Ø1,8 mm jacket, aqua colour

GGM D4MLCLC1M
LC/LC OM3 50/125 µm duplex 2 m patchcord, LSZH Ø1,8 mm jacket, aqua colour

GGM D4MLCLC2M
LC/LC OM3 50/125 µm duplex 3 m patchcord, LSZH Ø1,8 mm jacket, aqua colour

GGM D4MLCLC3M
LC/LC OM3 50/125 µm duplex 5 m patchcord, LSZH Ø1,8 mm jacket, aqua colour

GGM D4MLCLC5M
LC/LC OM3 50/125 µm duplex 7 m patchcord, LSZH Ø1,8 mm jacket, aqua colour

GGM D4MLCLC7M
LC/LC OM3 50/125 µm duplex 10 m patchcord, LSZH Ø1,8 mm jacket, aqua colour

GGM D4MLCLC10M
LC/LC OM3 50/125 µm duplex 12 m patchcord, LSZH Ø1,8 mm jacket, aqua colour

GGM D4MLCLC12M
LC/LC OM3 50/125 µm duplex 15 m patchcord, LSZH Ø1,8 mm jacket, aqua colour

GGM D4MLCLC15M
LC/LC OM3 50/125 µm duplex 20 m patchcord, LSZH Ø1,8 mm jacket, aqua colour

GGM D4MLCLC20M
LC/LC OM3 50/125 µm duplex 1 m patchcord with short boot, LSZH 1,8 mm, aqua

GGM D4MLCLC1MSB
LC/LC OM3 50/125 µm duplex 2 m patchcord with short boot, LSZH 1,8 mm, aqua

GGM D4MLCLC2MSB
LC/LC OM3 50/125 µm duplex 3 m patchcord with short boot, LSZH 1,8 mm, aqua

GGM D4MLCLC3MSB
LC/LC OM3 50/125 µm duplex 5 m patchcord with short boot, LSZH 1,8 mm, aqua

GGM D4MLCLC5MSB
LC/LC OM3 50/125 µm duplex 10 m patchcord with short boot, LSZH 1,8 mm, aqua

GGM D4MLCLC10MSB
LC/SC OM3 50/125 µm duplex 1 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MCLC1M
LC/SC OM3 50/125 µm duplex 2 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MCLC2M
LC/SC OM3 50/125 µm duplex 3 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MCLC3M
LC/SC OM3 50/125 µm duplex 5 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MCLC5M
LC/SC OM3 50/125 µm duplex 7 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MCLC7M
LC/SC OM3 50/125 µm duplex 10 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MCLC10M
LC/SC OM3 50/125 µm duplex 15 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MCLC15M
LC/SC OM3 50/125 µm duplex 20 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MCLC20M
SC/SC OM3 50/125 µm duplex 1 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MCC1M
SC/SC OM3 50/125 µm duplex 2 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MCC2M
SC/SC OM3 50/125 µm duplex 3 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MCC3M
SC/SC OM3 50/125 µm duplex 5 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MCC5M
SC/SC OM3 50/125 µm duplex 7 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MCC7M
SC/SC OM3 50/125 µm duplex 10 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MCC10M
SC/SC OM3 50/125 µm duplex 15 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MCC15M
SC/SC OM3 50/125 µm duplex 20 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MCC20M
LC/ST OM3 50/125 µm duplex 1 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTLC1M
LC/ST OM3 50/125 µm duplex 2 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTLC2M
LC/ST OM3 50/125 µm duplex 3 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTLC3M
LC/ST OM3 50/125 µm duplex 5 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTLC5M
LC/ST OM3 50/125 µm duplex 7 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTLC7M
LC/ST OM3 50/125 µm duplex 10 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTLC10M
LC/ST OM3 50/125 µm duplex 15 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTLC15M
LC/ST OM3 50/125 µm duplex 20 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTLC20M
ST/ST OM3 50/125 µm duplex 1 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTT1M
ST/ST OM3 50/125 µm duplex 2 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTT2M
ST/ST OM3 50/125 µm duplex 3 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTT3M
ST/ST OM3 50/125 µm duplex 5 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTT5M
ST/ST OM3 50/125 µm duplex 10 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTT10M
ST/SC OM3 50/125 µm duplex 1 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTC1M
ST/SC OM3 50/125 µm duplex 2 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTC2M
ST/SC OM3 50/125 µm duplex 3 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTC3M
ST/SC OM3 50/125 µm duplex 5 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTC5M
ST/SC OM3 50/125 µm duplex 7 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTC7M
ST/SC OM3 50/125 µm duplex 10 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTC10M
ST/SC OM3 50/125 µm duplex 15 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTC15M
ST/SC OM3 50/125 µm duplex 20 m patchcord, LSZH Ø3 mm jacket, aqua colour

GGM D4MTC20M
Multimode OM3 duplex aqua patchcord, SC/PC to SC/PC 1M

GGM DP4CC1M
Multimode OM3 duplex aqua patchcord, SC/PC to SC/PC 2M

GGM DP4CC2M
Multimode OM3 duplex aqua patchcord, SC/PC to SC/PC 3M

GGM DP4CC3M
Multimode OM3 duplex aqua patchcord, SC/PC to SC/PC 5M

GGM DP4CC5M
